Key Features

1. Developed on the basis of Intel chip E810;

2. It supports 10G/25G/50G/100G multiple rates;

3. It can enhance DPDK to be more efficient and flexible in packet forwarding and packet processing.

Key Features

1. Dynamic Device Personalization (DDP)

2. Supports both RDMA iWARP and RoCEv2

3. Application Device Queues (ADQ)

4. IEEE 1588 Precision Time Protocol (PTP)

10 G

A PCI Express network card, also known as a PCIe Network Card, is a hardware device used to connect a computer to a local area network (LAN) or the internet. It is designed to provide a high-speed and reliable network connection by utilizing the PCI Express interface.

Features

High Performance

Higher potential bandwidth and greater flexibility than PCI

Advanced Features

Support for multiple network protocols, VLAN tagging, and advanced network management capabilities

Multi-Scheme

Multiple solutions such as Intel/Broadcom/Mel1anox chips

RDMA Technology

RDMA technology provides high bandwidth, low latency, and broad compatibility for cloud storage targets

Series Products

LREC9804BT

PCIe 3.0 x8 | Intel XL710 | 10G | RJ45 | Quad-port

Product

Quad-port 10GbE adapter
PCI Express (PCIe) v3.0, 8.0 GT/s, x8 lanes
RJ45 Connectivity
Network Virtualization
Data Plane Development Kit (DPDK) support
Excellent small packet performance for network appliances and Network Functions Virtualization (NFV)
Low Profile and Full Height Bracket

LRES1024PF-4SFP+

PCIe 3.0 x8 | Intel 82599 | 10G | SFP+ | Quad-port

Product

A fiber 10G ethernet network adapter based on Intel chips.
This adapter card has 4 fully integrated 10 Gigabit Ethernet media access controllers (MAC) and SFP+ ports.
Provides Intel Virtualization Technology (VT-c) including the network layer, which can significantly improve the overall system performance in a virtual server environment.
Support a unified network and transform the data center with outstanding reliability, scalability and mobility.

LREC9804BF-4SFP+

PCIe 3.0 x8 | Intel XL710 | 10G | SFP+ | Quad-port

Product

Quad-port 10G SFP+ Connectivity
PCI Express (PCIe) v3.0 (8.0GT/s) x8 lanes
Network Virtualization
PXE boot
IEEE 802.1q VLAN support with VLAN tag insertion
Half height & full-height bracke

LRES1030PF-4SFP+

PCIe 3.0 x8 | Mucse N10G | 10G | SFP+ | Quad-port

Product

10 Gigabit PCIe3.0 x8 optical ethernet network adapter with quad port ;
This adapter is mainly designed to be applied to servers,network security and their application devices;
Intel quad-port Ethernet MAC+PHY controller with 10Gb/s speed;

LRES1050PF-SFP+

PCIe 2.0 x4 | mucse N400L-X4 | 10G | SFP+ | Single-port

Product

Support PCIe Gen 2.0x4;
Equipped with 1 10G SFP+ interface, supporting 1Gbps and 10Gbps data transmission rates;
Working temperature: 0°C~50°C (commercial grade);40°C~85°C (industrial grade)

LRES1016PF-SFP+

PCIe 2.0 x4 | Intel 82599 | 10G | SFP+ | Single-port

Product

PCIe x4 single-port optical fiber 10G Ethernet network adapter;
Support TCP/UDP/IP verification, offload, calculation tasks and TCP segmentation, etc.;
PCIe 2.0(5.0GT/S) X4, compatible with x8, x16;
It support iSCSI, FCoE, PXE and other boot.

LRES1010PF-2SFP+

PCIe 3.0 x8 | Intel Chip | 10G | SFP+ | Dual Port

Product

iWARP RDMA Support;
Dual SFP+ Connectivity;
PCI Express (PCIe) v3.0 (8.0GT/s) x8 lanes;
Network Virtualization offloads:VXLAN,GENEVE,and NVGRE;
Boot support (PXE, UEFI, iSCSI);
DPDK optimized for efficient packet processing.

LREC9812AF-2SFP+

PCIe 2.0 x8 | BCM57810 | 10G | SFP+ | Dual-port

Product

Dual Port 10GbE Adapters
PCI Express (PCIe) v2.0, 5.0 GT/s, x8 lanes
Industry standard SFP+ fiber port
PXE,iSCSI boot
Network Virtualization
Support IEEE 802.1Q VLAN
Low profile and full-height bracket

LREC9801BF-SFP+

PCIe 2.0 x8 | Intel 82599 | 10G | SFP+ | Single-port

Product

Single/Dual Port 10GbE Adapters
PCI Express (PCIe) v2.0, 5.0 GT/s, x8 lanes
Industry standard SFP+ fiber port
PXE ,iSCSI boot
Network Virtualization
Support IEEE 802.1Q VLAN
Low profile and full-height bracket

LRES1015PF-4SFP+

PCIe 3.0 x8 | Intel XL710 | 10G | SFP+ | Quad-port

Product

One provides inward and outward bidirectional 10G SFP + interface;
Convenient to use in firewall, gateway and other equipment environments;
This adapter card can be bundled and assembled into groups to achieve fault tolerance and redundancy to ensure network performance and expand network bandwidth.

LREC9802BF-2SFP+

PCIe 2.0 x8 | Intel 82599 | 10G | SFP+ | Dual-port

Product

Dual Port 10GbE Adapters
PCI Express (PCIe) v2.0, 5.0 GT/s, x8 lanes
Industry standard SFP+ fiber port
PXE,iSCSI boot
Network Virtualization
Support IEEE 802.1Q VLAN
Low profile and full-height bracket

LREC9812BF-2SFP+

PCIe 3.0 x8 | Intel X710 | 10G | SFP+ | Dual-port

Product

Dual-port 10GbE server adapters
PCI Express (PCIe) v3.0, 8.0 GT/s, x8 lanes
SFP+ Connectivity
PXE,iSCSI boot
Exceptional Low Power Adapters
IEEE 802.3ad and 10G Ethernet specification compliance
Data Plane Development Kit (DPDK) support
Excellent small packet performance for network appliances and Network Functions Virtualization (NFV)
Low Profile and Full Height Bracket

LRES1003PF-SFP+

PCIe 3.0 x8 | Net-swift SP1000A | 10G | SFP+ | Single-port

Product

LRES4005TF-2S2T

PCIe 3.0 x8 | Intel X710 | 10G | SFP+ & Copper | Quad-port

Product

A 10Gbps PCIe X8 Ethernet network adapter with dual port and dual fiber hybrid;
This adapter is mainly designed to be applied to servers and their application devices;
Intel 4-port Ethernet MAC+PHY controller with multi-megabit speed;
Newly added NBAE-T support for 2.5G and 5.0G with adaptive link rates.

LRES1002PF-2SFP+

PCIe 3.0 x8 | Net-swift SP1000A | 10G | SFP+ | Dual-port

Product

PCI Express v3.0 x8
Netswift SP1000A Chipset
The first China-Made Chip master control solution
Full-height and low profile bracket
2 years warranty
Operating temperature -25 ℃ to 70 ℃ (-13 ℉ to 158 ℉)

LRES1031PF-2SFP+

PCIe 3.0 x8 | Mucse N10G | 10G | SFP+ | Dual-port

Product

10 Gigabit PCIe3.0 x8 optical ethernet network adapter with dual port ;
This adapter is mainly designed to be applied to servers,network security and their application devices;
Intel dual-port Ethernet MAC+PHY controller with 10Gb/s speed;

Filter Criteria:

Resetting

Filtered out: 1 products

Model	Ports	Connector	Rate	PCle	Chip	Contrast
LREC7020PF	Single-port	SC	100Mbps		VT6105MT
